MH511 – Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

Table of Contents

Introduction

In this article, we’ll walk you through the step-by-step process of completing the workflow for sending Sales Order picklist transaction data from an external Warehouse Management System (WMS) to Dynamics 365FO using an HTTP trigger and POST action in Azure Logic Apps. Additionally, I’ll demonstrate how to properly close the transaction in Dynamics to ensure smooth synchronization between systems. This guide will help you automate the final stages of the integration, ensuring that sales order picklist transactions are accurately processed and reflected in D365FO.

Goal

Note – both screenshots represent single workflow. I had to take two different screenshot due to lake of capturing single screenshot of entire logic app workflow.

Pick Line

image-66 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

Put Line

image-67 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

Configuring workflow – Step by Step

1.  HTTP Trigger

  • Add trigger
image-68 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
  • Configure trigger
image-69 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

2. Initialise variable

  • Add action
image-70 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
  • Configure action
image-71 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

3. Parse Json

  • Add Action
image-72 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
  • Configure Action
image-73 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

4. Scope

image-74 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

5. Condition

  • Add Action
image-75 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
  • Configure condition
image-76 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

6. True condition

  • Configure

D365 MHAX Inbound message API –

https://XXXX.dynamics.com/api/services/WMHEServices/WMHEService/executeInboundTransaction

image-77-894x1024 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

7. False condition

  • Configure
image-78-772x1024 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

8. Scope2 for Put line

  • Add Action
image-79 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

9.  Get Blob Content

  • Add Action
image-80 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
  • Configure Action
image-81 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

10. Compose – Get content

  • Add Action
image-82 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
  • Configure Action
image-83 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

11. Parse Json

  • Configure Action
image-84 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

12. HTTP Post

  • Configure Action
image-85-769x1024 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

Run and Test

Full Pick Test

1. Reset status of existing message. Feel free to create new transaction.

image-86 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

2. Verify Logic app run

image-87 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

3. Verify Transaction in your External WMS system

4. Complete Picklist in External WMS

5. Ensure External WMS is sending Pick List message to Logic app trigger endpoint

6. Once Triggered, Verify Logic app

image-88 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

7. Verify Put line message parsed correctly

image-89 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

8. Verify MHAX Inbound queue

image-90 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

9. Verify Closure of Work

image-91 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

Short Pick

1. Reset status of existing message. Feel free to create new transaction.

image-92 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

2. Verify Logic app run

image-93 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

3. Verify Transaction in your External WMS system

4. Complete Picklist in External WMS – ShortPicking

5. Ensure External WMS is sending Pick List message to Logic app trigger endpoint

6. Once Triggered, Verify Logic app

image-94 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

7. Verify Put line message parsed correctly

8. Verify MHAX Inbound queue

image-95 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger

9. Verify Closure of Work

image-96 MH511 - Integrating External WMS with D365FO MHAX: Completing Sales Order Picklist Transactions via Logic App HTTP Trigger
